HYDRAULIC PISTON PUMP PARTSA10VO28 A10VO140 A10VO100DFR1 SET PLATE VALVE PLATE CYLINDER BLOCK
Rexroth Excavator Spare Parts - Hydraulic Pump A10VSO 45 DFR/31R-PPA12N00
- Size 18 (A10VSO)
- Sizes 28 to 140 (A10VO)
- Nominal pressure: 280 bar
- Maximum pressure: 350 bar
- Open circuit design
- Variable pump with axial piston rotary group in swashplate design
- Flow proportional to drive speed and displacement
- Infinitely variable flow via swashplate angle adjustment
- 2 drain ports
- Excellent suction performance
- Low noise level
- Long service life
- Favorable power/weight ratio
- Versatile controller range
- Short control time
Key Features
- Variable displacement pump with axial piston rotary group
- Hydrostatically unloaded cradle bearing
- Port for measurement sensor on high pressure port
- Increased functional reliability
- High efficiency
- Universal through drive for all sizes
- Optional pulsation damping
Technical Specifications
| Size |
45 |
71 |
100 |
140 |
180 |
| Displacement geometric, per revolution (Vg max cm³) |
45 |
71 |
100 |
140 |
180 |
| Nominal pressure (pnom bar) |
280 |
280 |
280 |
280 |
280 |
| Maximum pressure (pmax bar) |
350 |
350 |
350 |
350 |
350 |
| Maximum speed at Vg max (nnom rpm) |
1800 |
1800 |
1800 |
1800 |
1800 |
| Flow at Vg max and nnom (qV nom l/min) |
81 |
128 |
180 |
252 |
324 |
| Flow at Vg max and n=1500 rpm (qV 1500 l/min) |
67.5 |
106.7 |
150 |
210 |
270 |
| Power at qV nom and pnom (P kW) |
38 |
59.7 |
84 |
118 |
151 |
| Torque at Vg max and pnom (M Nm) |
200 |
317 |
446 |
624 |
802 |
| Weight approx. (m kg) |
30 |
47 |
69 |
73 |
78 |
About BETTERPARTS
BETTERPARTS specializes in research, development, manufacturing and after-sales service for hydraulic pump pressure brand products. With extensive experience in the injection molding machine, die-casting, hydraulic station, and engineering machinery industries, we have established a professional after-sales team and earned an excellent reputation in the hydraulic industry.
Our company operates with the principle of "customer first, high-quality service, and abiding by contracts". Our products are sold throughout nearly 30 provinces and exported to countries including Malaysia, India, Southeast Asia, and Australia. We welcome cooperation with domestic and international partners for mutual development.
Compatible Part Numbers
R902469087 | AA10VSO140LA6S/32R-VSB22U99
R902492308 | AA10VSO140LA5D/32R-VPB22U99
R902464819 | AA10VSO140LA6D/32R-VKD72U99
R902465294 | AA10VSO140LA6D/32R-VKD72U99E
R902482706 | AA10VSO140LA6D/32R-VPB22U68
R902444124 | AA10VSO140LA6D/32R-VPB32U99
R902490763 | AA10VSO140LA6DG/32R-VSD72U17E
R902490762 | AA10VSO140LA6DG/32R-VSD72U99E
R902494538 | AA10VSO140LA6DS/32R-VKD72U99SO413
R902453223 | AA10VSO140LA7D/32R-VPB32U99
R902551907 | AA10VSO140LA7S/32R-VSB22U00E
R902453128 | AA10VSO140LA5D/32R-VPB12N00
R902477642 | AA10VSO140LA5DS/32R-VSB22U99
R902460051 | AA10VSO140LA5S/32R-VPB12N00
R902452754 | AA10VSO140LA6D/32R-VPB12N00
R902513427 | AA10VSO140LA6DG/32R-VPB32U00E
R902460112 | AA10VSO140LA6DG/32R-VPB32U99
R902544311 | AA10VSO140LA6DG/32R-VSB22U00E-SO52
R902551880 | AA10VSO140LA6DG/32R-VSD72U00E
R902467497 | AA10VSO140LA6DS/32R-VSB22U99
R902463149 | AA10VSO140LA6DS/32R-CPB22U99-SO52
R902463150 | AA10VSO140LA6DS/32R-CPB32U99-SO52
R902577437 | AA10VSO140LA6DS/32R-VPB12N00
R902449952 | AA10VSO140LA6DS/32R-VPB12N00
R902577436 | AA10VSO140LA6DS/32R-VPB12N00
R902577432 | AA10VSO140LA6DS/32R-VPB12N00*GOEU*
R902454865 | AA10VSO140LA6DS/32R-VPB22U99
R902518672 | AA10VSO140LA6DS/32R-VPB32U00E
R902544614 | AA10VSO140LA6DS/32R-VPB32U00E
R902514720 | AA10VSO140LA6DS/32R-VPB32U68E
R902454562 | AA10VSO140LA6DS/32R-VPB32U99
R902490866 | AA10VSO140LA6DS/32R-VSB22U52
R902489612 | AA10VSO140LA6DS/32R-VSB22UB9
R902513638 | AA10VSO140LA6DS/32R-VSB32U00E
R902532674 | AA10VSO140LA6DS/32R-VSB32U00E*GO2EU*
R902468668 | AA10VSO140LA6DS/32R-VSB32U99
R902467373 | AA10VSO140LA6DS/32R-VSB32UB7
R902460767 | AA10VSO140LA6DS/32R-VSB32UB9
R902491914 | AA10VSO140LA6DS/32R-VSB32UE1Z-SO52
A10VSO Series Compatible Models
A10VSO 18 series:
A10VSO18DR/31R-PPA12N00
A10VSO18DR/31R-PPA12K01
A10VSO18DFR1/31R-PPA12N00
A10VSO18DFR1/31R-PPA12K01
A10VSO18DFR/31R-PPA12N00
A10VSO18DFLR/31R-PPA12N00
A10VSO18DG/31R-PPA12N00
A10VSO18DRG/31R-PPA12N00
A10VSO18DFE1/31R-PPA12N00
A10VSO18FHD/31R-PPA12N00
A10VSO18ED/31R-PPA12N00
A10VSO 28 series:
A10VSO28DR/31R-PPA12N00
A10VSO28DR/31R-PPA12K01
A10VSO28DFR1/31R-PPA12N00
A10VSO28DFR1/31R-PPA12K01
A10VSO28DFR/31R-PPA12N00
A10VSO28DFLR/31R-PPA12N00
A10VSO28DG/31R-PPA12N00
A10VSO28DRG/31R-PPA12N00
A10VSO28DFE1/31R-PPA12N00
A10VSO28FHD/31R-PPA12N00
A10VSO28ED/31R-PPA12N00
A10VSO 45 series:
A10VSO45DR/31R-PPA12N00
A10VSO45DR/31R-PPA12K01
A10VSO45DFR1/31R-PPA12N00
A10VSO45DFR1/31R-PPA12K02
A10VSO45DFR/31R-PPA12N00
A10VSO45DFR/31R-PPA12K01
A10VSO45DFR/31R-PPA12K26
A10VSO45DFLR/31R-PPA12N00
A10VSO45DG/31R-PPA12N00
A10VSO45DRG/31R-PPA12N00
A10VSO45DFE1/31R-PPA12N00
A10VSO45FHD/31R-PPA12N00
A10VSO45ED/31R-PPA12N00
A10VSO 71 series:
A10VSO71DR/31R-PPA12N00
A10VSO71DR/31R-PPA12K01
A10VSO71DFR1/31R-PPA12N00
A10VSO71DFR1/31R-PPA12K02
A10VSO71DFR/31R-PPA12N00
A10VSO71DFR/31R-PPA12K27
A10VSO71DFLR/31R-PPA12N00
A10VSO71DG/31R-PPA12N00
A10VSO71DRG/31R-PPA12N00
A10VSO71DFE1/31R-PPA12N00
A10VSO71FHD/31R-PPA12N00
A10VSO71ED/31R-PPA12N00
A10VSO 100 series:
A10VSO100DR/31R-PPA12N00
A10VSO100DR/31R-PPA12K01
A10VSO100DFR1/31R-PPA12N00
A10VSO100DFR1/31R-PPA12K01
A10VSO100DFR/31R-PPA12N00
A10VSO100DFLR/31R-PPA12N00
A10VSO100DG/31R-PPA12N00
A10VSO100DRG/31R-PPA12N00
A10VSO100DFE1/31R-PPA12N00
A10VSO100DFE1/31R-PPA12K02
A10VSO100FHD/31R-PPA12N00
